| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: | 144-146 MHz (200 channels with VXO) |
| Tuning steps: | 10 KHz + VXO (±7 KHz) |
| Frequency stability: | Max ? ppm |
| Mode: | FM / SSB / CW |
| Channels / memory management: | 3, 4 or 5 (Depending on version), XTAL controlled |
| Repeater shift / offset: | See additional info below |
| Power supply: | Mains: 220 VAC
or 13.5 VDC |
| Current drain / power consumption: | RX: ? mA
TX: Max 3.2 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 340*85*295 mm (13.39*3.35*11.61") |
| Weight: | 7 Kg (15.43 lb) |
| Other features: | NB. RIT. |
|
|
